Multimeter, Professional Grade Digital

Multimeter, Professional Grade Digital
Fully Featured Multimeters
Design for measuring AC/DC Volts, Current, Resistance, Frequency, Temperature, Continuity, Diode and Transistor.

Versatile, safe and Accurate
All of its inputs are protected to CE, IEN61010-1 CAT IV 600V safety rated and overload protection ensures uninterrupted operation and long life.Dual slope A/D conversion.

Large LCD with back-light
LCD display with back-light allows for easy reading even in dark area.

Extra functions
Continuity with beeper, Diode test, Data hold, Auto power off, Low battery indication, Overload indication, Back-light, Transistor Tester.

Our PriceUS$60.00
Retail PriceUS$64.99
CodeMT-5211
Stock1
Weight1
addthis
Save wishlist
Add to comparison chart | Compare Products

LCR Meter
  • Inductance to 20H
  • Capacitance to 200µF
  • Resistance to 2000MΩ
Specifications
DC Voltage (V) 200mV/2V/20V/200V±(0.5%+3d) 1000V±(1.0%+5d)
AC Voltage (V)   200mV±(1.2%+3d) 2V/20V/200V±(0.8%+5d) 750V±(1.2%+5d)
DC Current (A) 2mA/20mA±(0.8%+3d) 200mA±(1.2%+4d) 20A±(2.0%+5d)
AC Current (A)   2mA/20mA±(1.0%+5d) 200mA±(2.0%+5d) 20A±(3.0%+10d)
Resistance (Ω) 200±(0.8%+5d) 2K/20K/200K/2MΩ±(0.8%+3d) 20MΩ±(1.0%+15d) 2000MΩ±(5.0%(reading-10)+20d)
Capacitance (uF) 20nF/200nF/2uF±(2.5%+20d) 20uF/200uF±(5.0%+5d)
Inductance (L) 2mH/20mH/200mH/2H/20H±(2.5%+20d)
Temperature (T) <400°±(1.0%+4d) ≥400°±(1.5%+15d)
Frequency (Hz) 2k/20k/200k/2000K/10M Hz±(1.0%+10d)
Power source 9V 6F22 battery
Dimensions 7.4x3.8x1.4"
